DLAB MX-M Microplate Mixer

• Wide range of speed from 0 to 1,500 rpm (Double microplate:0-1,000 rpm)

• Excellent performance with electronic speed control

• High speed and effective mixing for microplates

• With adapters for most popular vessels and microtiter plates

• Used for various mixing applications with optional adapters

• Maintenance-free brushless DC motor

Adaptors and Accessories

Note: A standard Microplate clamp is included.

See all clamps, adaptors, heads/accessories -see the pictures as well as this attached description on clamps, adaptors and accessories, download here.

If you are purchasing more than one additional adaptor, please order the desired number of adaptors and specify the adaptor type in your order. Thanks.

Specifications

Parameter	Value
Motion type	Orbital
Orbital diameter	4.5mm
Speed range	Single microplate: 0-1500rpm \| Double microplate: 0-1000rpm
Speed display	Scale
Max. load capacity (with platform)	0.5kg
Motor type	Brushless DC motor
Motor rating input	18W
Motor rating output	10W
Power	20W
Voltage	100-240V
Frequency	50/60Hz
Dimension [D×W×H]	260×150×80mm
Weight	3kg
Permissible ambient temperature	5-40℃
Permissible relative humidity	80% RH
Protection class	IP20

Product Information

Shipping & Returns

DLAB MX-M Microplate Mixer

Name: DLAB MX-M Microplate Mixer
Brand: GeneBio
SKU: copy-of-mx-s-variable-speed-vortex
Availability: InStock

• Wide range of speed from 0 to 1,500 rpm (Double microplate:0-1,000 rpm)

• Excellent performance with electronic speed control

• High speed and effective mixing for microplates

• With adapters for most popular vessels and microtiter plates

• Used for various mixing applications with optional adapters

• Maintenance-free brushless DC motor

Adaptors and Accessories

Note: A standard Microplate clamp is included.

See all clamps, adaptors, heads/accessories -see the pictures as well as this attached description on clamps, adaptors and accessories, download here.

If you are purchasing more than one additional adaptor, please order the desired number of adaptors and specify the adaptor type in your order. Thanks.

Specifications

Parameter	Value
Motion type	Orbital
Orbital diameter	4.5mm
Speed range	Single microplate: 0-1500rpm \| Double microplate: 0-1000rpm
Speed display	Scale
Max. load capacity (with platform)	0.5kg
Motor type	Brushless DC motor
Motor rating input	18W
Motor rating output	10W
Power	20W
Voltage	100-240V
Frequency	50/60Hz
Dimension [D×W×H]	260×150×80mm
Weight	3kg
Permissible ambient temperature	5-40℃
Permissible relative humidity	80% RH
Protection class	IP20

Select Size

From $1,239.08

Original: $4,130.28

-70%

DLAB MX-M Microplate Mixer—

$4,130.28

$1,239.08

Select Size

From $1,239.08

Original: $4,130.28

-70%

DLAB MX-M Microplate Mixer—

$4,130.28

$1,239.08

Product Information

Shipping & Returns

Description

• Wide range of speed from 0 to 1,500 rpm (Double microplate:0-1,000 rpm)

• Excellent performance with electronic speed control

• High speed and effective mixing for microplates

• With adapters for most popular vessels and microtiter plates

• Used for various mixing applications with optional adapters

• Maintenance-free brushless DC motor

Adaptors and Accessories

Note: A standard Microplate clamp is included.

See all clamps, adaptors, heads/accessories -see the pictures as well as this attached description on clamps, adaptors and accessories, download here.

If you are purchasing more than one additional adaptor, please order the desired number of adaptors and specify the adaptor type in your order. Thanks.

Specifications

Parameter	Value
Motion type	Orbital
Orbital diameter	4.5mm
Speed range	Single microplate: 0-1500rpm \| Double microplate: 0-1000rpm
Speed display	Scale
Max. load capacity (with platform)	0.5kg
Motor type	Brushless DC motor
Motor rating input	18W
Motor rating output	10W
Power	20W
Voltage	100-240V
Frequency	50/60Hz
Dimension [D×W×H]	260×150×80mm
Weight	3kg
Permissible ambient temperature	5-40℃
Permissible relative humidity	80% RH
Protection class	IP20
